Description
Boasting some impressive features, the ZJ Longarm Kit is a comprehensive package including everything needed for a great suspension lift while maintaining the vehicle’s crucial center of gravity. The kit includes adjustable high-clearance X-Flex upper and lower control arms with Clevite bushings, featuring X-Flex joints.
This lift kit features high-clearance components with a front y-link and rear 4-link control arm design. This promotes extreme axle flex while keeping pinion angles optimized.
Features:
- Aggressive appearance
- Increased ground clearance
- HD 0.25 inch thick crossmember
- Lower control arms feature high clearance design
- Extreme travel long arms keep optimum alignment and give optimum articulation
- X-Flex control arm features
- Clevite brand OEM style rubber bushings
- Flex joints feature a massive 2.5 Inch diameter body and 1. 25 inch thread
- Fully greasable
- Upper joints pivot up to 20 degrees
- Lower joints pivot up to 35 degrees
Notes:
- Does Not fit AWD models
- Transfer case skid plate Will Not fit models equipped with 249 transfer case.
- Exhaust will have to be cut and rerouted to make sure it is away from the moving components.
- Models equipped with a CV style front driveshaft may result in driveshaft vibration.
- If this occurs, replacing the driveshaft, axle yoke and, or transfer case yoke will need to be performed to rid the vehicle of driveline vibration.
- CV Driveshaft Example
Details:
- Sold As Kit
- Drive 4WD
- Lift Height 4.0 inch
- Thickness 0.25 inch
- Front Components Adjustable upper control arms Adjustable lower control arms Crossmember Transfer case skid plate Sway-bar quick disconnects 3 Inch Bumpstops Hardware
- Rear Components Adjustable upper control arms Adjustable lower control arms Long arm frame brackets Track bar bracket Bumpstop brackets Brake line brackets Hardware
Resources
Installation Instructions
Specifications:
| brand_logo | https://www.asapnetwork.org/sites/default/files/brands/icons/rough%20country%20asap.jpg |
| Description_ASC | Does NOT fit AWD models. Transfer case skid plate will NOT fit models equipped with 249 transfer case. Exhaust will have to be cut and rerouted to make sure it is away from the moving components. Models equipped with a CV style front driveshaft may result in driveshaft vibration. If this occurs, replacing the driveshaft, axle yoke and / or transfer case yoke will need to be performed to rid the vehicle of driveline vibration. CV Driveshaft Example |
| Description_ASC | Manufacturer: Rough Country Suspension Systems; Part Number: 90200U; Weight (Lbs): 212.55; Install Time (Hours): 8-9 |
| Description_ASM | 1993-1998:4WD:Jeep:Grand Cherokee |
| Description_ASM | Jeep: 93-98 Grand Cherokee ZJ 4WD |
| Description_DEF | Suspension Control Arm Kit |
| Description_DES | X-Flex Long Arm Upgrade Kit |
| Description_DES | X-Flex Long Arm Upgrade Kit for 4-inch Lifts |
| Description_EXT | Contents: Adj high-clear Lwr control arms, Adj Up control arms, 1/2″ thick crossmbr, transfer case skid plate, sway bar quick discon, 3″ bumpstops; Adj high-clear Lwr control arms, Adj Up control arms, long arm frame brkts, track bar brkt, |
| Description_EXT | Long Arm Upgrade Kit – 4 Inch Lift – Jeep Grand Cherokee ZJ (93-98) |
| Description_EXT | X-Flex Long Arm Upgrade Kit; For 4 in. Lift; Incl. Front And Rear Control Arms; 0.5 in. Thick Cross Member; Skid Plate; Sway Bar Disconnects; Bump Stops; Track Bar Bracket; |
| Description_FAB | 25″ thick crossmember |
| Description_FAB | Aggressive Appearance |
| Description_FAB | Clevite Brand Orem Style Rubber Bushings. |
| Description_FAB | Extreme Travel Long Arms |
| Description_FAB | Flex Joints Feature A Massive 2.5 Diameter Body And 1.25 Thread. |
| Description_FAB | Fully Greaseable. |
| Description_FAB | Had 0.25 Thick Crossmember |
| Description_FAB | Increased Ground Clearance |
| Description_FAB | Keep Optimum Alignment And Give Optimum Articulation |
| Description_FAB | Lower Control Arms Feature High Clearance Design |
| Description_FAB | Lower Joints Pivot Up To 35 Degrees. |
| Description_FAB | Upper joints pivot up to 20 degrees |
| Description_FAB | Upper Joints Pivot Up To 20 Degrees. |
| Description_FAB | X-flex Control Arm Features: |
| Description_INV | Rough Country Long Arm Upgrade Kit |
| Description_MKT | Boasting some impressive features, the ZJ Longarm Kit is a comprehensive package including everything needed for a great suspension lift while maintaining the vehicle’s crucial center of gravity. The kit includes adjustable high-clearance X-Flex upper and lower control arms with Clevite bushings, featuring X-Flex joints. This lift kit features high-clearance components with a front y-link and rear 4-link control arm design. This promotes extreme axle flex while keeping pinion angles optimized. |
| Description_MKT | Boasting some impressive features, the ZJ Longarm Kit is a comprehensive package including everything needed for a great suspension lift while maintaining the vehicles crucial center of gravity. The kit includes adjustable high-clearance X-Flex upper and lower control arms with Clevite bushings, featuring X-Flex joints. This lift kit features high-clearance components with a front y-link and rear 4-link control arm design. This promotes extreme axle flex while keeping pinion angles optimized. |
| Description_SHO | Long Arm Upgrade Kit |
| Description_SHO | SuspUpKt |
| drive | 4WD |
| height | 10.0 |
| Install Time | 8-9 hours |
| installation_time | 8-9 hours |
| last_update | 2023-04-18 13:54:27 |
| length | 45.5 |
| lift_height | 4.0 inch |
| Position | Front and Rear |
| prop_65_warning | CALIFORNIA WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
| Rear Kit Components | Adjustable upper control arms, Adjustable lower control arms, Long arm frame brackets, Track bar bracket, Bumpstop brackets, Brake line brackets, Hardware |
| sold_as | Kit |
| Thickness | 0.25 inch |
| Title | Long Arm Upgrade Kit – 4 Inch Lift – Jeep Grand Cherokee ZJ (93-98) |
| Title | Rough Country X-Flex Long Arm Upgrade Kit for 4-inch Lifts |
| Universal | No |
| vehicle_type | Jeep |
| WARNING CA Proposition 65 | No |
| weight | 65.3 |
| width | 11.25 |
